Description

EDWARDS PEARSON SBS CNC GUILLOTINE

Model:                  SBS-CNC-PPE-6.5 X 3200

Serial No:             210125A

MFD:                    March 2021

CNC Control:      EP 07

Capacity:

Maximum Material Width:        3200mm

Maximum Material Thickness:  6.5mm

Throat Depth:                            140mm

Shear Angle:                              1’ 30’

Back Gauge Stroke:                   1000mm

Table Height:                             870mm

Complete With:

Blade Gap Adjustment

Finger Guard

Infrared Rear Guards

4 Sheet Supports

Table Top Rollers

8 No Hydraulic Material Clamps

Cut Off Shute

Rear Light Guards

Electrics:      415v, 3ph, 50 Cycles

Motor:         10Kw

Approximate Dimensions:         3800 x 2520 x 1870mm

Approximate Weight:                7200kg
